Balustrade Raking Panel Classic

The Steeline FNW Classic Balustrade Raking Panel is purpose-built to provide a secure and visually consistent safety barrier along stairs and sloped walkways. Designed to match the Classic Balustrade Panel, it features the same square-profile design with robust construction and clean, symmetrical lines.

Made from powder-coated aluminium, the panel includes 50x50mm square top and bottom rails for a solid frame, along with 25x25mm square vertical tubes spaced at 95mm centres to ensure safety and style. With a panel height of 950mm, it sits on a centre leg that raises it 100mm off the ground—achieving a total installed height of over 1 metre.

Key Features:

• Designed for staircases and sloped areas in the Classic Balustrade range
• 50x50mm square aluminium top and bottom rails for bold, structured appearance
• 25x25mm square vertical tubes at 95mm centres for safety and uniformity
• 950mm panel height, raised to over 1 metre with centre support leg
• Maximum raking angle up to 45 degrees but generally recommend between 30 and 38 degrees
• Powder-coated aluminium for durability, corrosion resistance, and low maintenance
